Using the Cinema4D Retarget Tag to Switch Between Rokoko Animations

In this tutorial, Sam guides us through how to record custom motion capture animations in Rokoko Studio, bring them into Cinema4D and then use the Retarget Tag to quickly and easily switch between different Rokoko Studio animations. This means that once you have bound a character to a single Rokoko animation, adding new animations is a breeze!

This blog serves as a step-by-step guide for users who want to learn how to use the Retarget Tag in Cinema4D to switch between different motion capture animations from Rokoko Studio. First we will set up your Rokoko Studio animation to drive your character, and then you can use the Retarget Tag to switch between different Rokoko Studio animations.

Exporting from Rokoko Studio

When you’re ready to export your recorded animations from Rokoko Studio:

  • Select your animations and click the “Export” button to bring up the the “Export options” box
  • Most of the default information should remain untouched, however, you have the option to adjust the following settings:
  1. If you have Virtual Production data, make sure “Export VP data” is checked
  2. “Mimic file hierarchy” will export your files in the same hierarchy that they are in Studio
  3. “Export Path” shows where the files will be exported out to
  4. Keep the file format as FBX and ASCII
  5. “Version” allows you to choose which version you’d like to export as
  6. “Skeleton” has four different options but for Cinema4D select either Rokoko Newton (Default) or Mixamo. NOTE: The Retarget Tag only allows you to switch between animations with the same skeleton, so all animations and future animations must use the same skeleton. Rokoko Newton is recommended.
  • Once you have your settings set, click the “Export” button

Importing Rokoko Studio Animations into Cinema4D

To import your animations:

  • Click “File>Merge….”
  • Locate the FBX file of your animation
  • Click on it then click the “Open” button

Method 1: Set Up Character Mesh without a Rig

To import your character:

  • Click “File>Merge…”
  • Locate the OBJ or FBX of your character mesh
  • Click on it then click the “Open” button
  • If your character mesh is split into different parts, select all parts of the character and right-click them, and select “Connect Objects + Delete.” This will give you a single mesh that you can bind to your Rokoko animation.
  • Move your character so that the Rokoko animation skeleton is within your character model. If your character model is not in a T-Pose you can move the joints into position by:
  • Turning on Auto-Keying
  • Rotate each joint so that it is positioned within your character mesh
  • To bind your Rokoko animation to your character mesh:
  • Select the top level of the Rokoko animation, right-click and select “Select Children.” This will select all of the joints in the animation
  • Control + click your character model to also select it
  • Click “Character>Commands>Bind”

Method 1: Use Retarget Tag to Switch between Animations

To switch between different Rokoko Studio animations exported with the same skeleton:

  • Select the Rokoko Studio animation driving your character mesh
  • Right-click and select “Character Tags>Retarget”
  • In the Retarget Tag, drag the current animation driving your character into the “Target” field
  • Drag any new animations into the “Source” field

Method 2: Set Up Character Mesh with a Rig

To import your character:

  • Click “File>Merge…”
  • Locate the OBJ or FBX of your character mesh
  • Click on it then click the “Open” button
  • We will apply the animation to the character by using constraints to bind the joints from the rigged character to the Rokoko Studio animation. NOTE: Rigged Character must be in T-Pose with hands face down at Frame 1, same as Rokoko Studio Animation.
  • To add constraints to each joint:
  • Right-click on a joint and select “Character Tags>Constraint”
  • Within the Attributes window under Constraints, check the “PSR” box (Position, Scale, Rotation)
  • Once this is checked, a “PSR” tab will appear, to the right of the “Basic” tab
  • Click the “PSR” tab and expand the “Offset” and “Targets” tabs
  • Within the “Offset” tab, click “Maintain Original” to keep the placement of the characters joints from moving
  • Within the “Targets” tab, drag and drop the relative joint from the Rokoko Studio animation (Hips to Hips, Spine to Spine, etc…)
  • Do this for all joints on character.

Method 2: Use Retarget Tag to Switch between Animations

To switch between different Rokoko Studio animations exported with the same skeleton:

  • Select the Rokoko Studio animation driving your character mesh - for Method 2 this would be the Rokoko Studio animation that you constrained your characters joints to
  • Right-click and select “Character Tags>Retarget”
  • In the Retarget Tag, drag the current animation driving your character into the “Target” field
  • Drag any new animations into the “Source” field
  • On the “Basic” tab, make sure the “Priority” drop down is set to “Animation”

We hope this guide has helped you set up your character properly in Cinema4D, and to switch between different Rokoko Studio animations using the Retarget Tag. If you have any questions or continue to run into issues please reach out to our support desk. Thank you!
